PopUpMessageButtonHandler Class Reference

#include <PopUpMessageButtonHandler.h>

Classes
class	DataClass

Public Member Functions
	PopUpMessageButtonHandler ()
	Constructor creates new handler and assigns it to the given pop-up message. More...
virtual	~PopUpMessageButtonHandler ()
void	OnButtonClicked (PopUpMessageWidget::Button button)
	OnButtonClicked method is called when a button is clicked in pop-up message window. The parameter identifies which button was clicked. More...
void	SetButtonAction (PopUpMessageWidget::Button button, ApplicationDefines::ButtonAction action)
	SetButtonAction sets action for a button identified by 'button' parameter. The action is an object of type ButtonAction, which is defined in class ApplicationDefines as follows: More...
void	SetButtonRepeat (PopUpMessageWidget::Button button)
	SetButtonRepeat if the button given as parameter is clicked, button action is executed again and message will be repeated. More...
bool	GetButtonRepeat (PopUpMessageWidget::Button button) const

Constructor & Destructor Documentation

PopUpMessageButtonHandler::PopUpMessageButtonHandler ( )

explicit

Constructor creates new handler and assigns it to the given pop-up message.

Parameters

parent

- pop-up message instance, which will own this handler

PopUpMessageButtonHandler::~PopUpMessageButtonHandler ( )

virtual

Member Function Documentation

bool PopUpMessageButtonHandler::GetButtonRepeat

(

PopUpMessageWidget::Button

button

)

const

void PopUpMessageButtonHandler::OnButtonClicked

(

PopUpMessageWidget::Button

button

)

OnButtonClicked method is called when a button is clicked in pop-up message window. The parameter identifies which button was clicked.

Parameters

button

- button that was clicked (enum type from PopUpMessageWidget)

void PopUpMessageButtonHandler::SetButtonAction	(	PopUpMessageWidget::Button	button,
		ApplicationDefines::ButtonAction	action
	)

SetButtonAction sets action for a button identified by 'button' parameter. The action is an object of type ButtonAction, which is defined in class ApplicationDefines as follows:

using ButtonAction = std::function<void()>;

This means that the action must be a callable object (object with operator() or a function) with no parameters. An example would be:

void func()
{
 puts("Ok button pressed");
}

class MyClass
{
public:
 void ShowMessage()
 {
    PopUpMessageButtonHandler *handler = new PopUpMessageButtonHandler();
    handler->SetButtonAction(PopUpMessageWidget::Ok, func);
    ...
 }
};

Often we want the function to have some parameters we need to use in the function. In that case, std::bind should be used. It binds parameters to a function before it is called, and returns a function with corresponding signature. For example:

void func(Widget *widget, int width, int height)
{
 widget->SetSize(width, height); // resize the widget
}

class MyClass
{
private:
 Widget *widget;
public:
 void ShowMessage()
 {
    PopUpMessageButtonHandler *handler = new PopUpMessageButtonHandler();
    ApplicationDefines::ButtonAction okAction = std::bind(func, widget, 800, 600); // std::bind returns an object of type std::function<void()>
    handler->SetButtonAction(PopUpMessageWidget::Ok, okAction);
    ...
 }
};

func() can also be a member function (which is better if we want to call private member functions or use private members). If the function is non-static, the first argument in std::bind call is the object on which we want to call the function. Example:

class Widget
{
private:
 int width;
 int height;
 void SetSize(int w, int h)
 {
    width = w;
    height = h;
 }
 static void NotResizedInfo()
 {
    puts("Widget was not resized!");
 }

public:
 void ShowMessage()
 {
    PopUpMessageButtonHandler *handler = new PopUpMessageButtonHandler();
    ApplicationDefines::ButtonAction okAction = std::bind(&Widget::SetSize, this, 800, 600); // non-static function, first argument has to be the object (in this case it's 'this')
    ApplicationDefines::ButtonAction cancelAction = Widget::NotResizedInfo; // static function, has no parameters
    handler->SetButtonAction(PopUpMessageWidget::Ok, okAction);
    handler->SetButtonAction(PopUpMessageWidget::Cancel, cancelAction);
 }
};

If the function is small, we can also use lambda functions. Setting an action for cancel button from the previous example can be replaced with:

handler->SetButtonAction(PopUpMessageWidget::Cancel, [](){ puts("Widget was not resized!"); });

If the lambda function is bigger, it makes the code less readable, so a normal function (or member function) should be used instead.

Parameters

button	- button for which the action is set
action	- action for the button

Here is the caller graph for this function:

void PopUpMessageButtonHandler::SetButtonRepeat

(

PopUpMessageWidget::Button

button

)

SetButtonRepeat if the button given as parameter is clicked, button action is executed again and message will be repeated.

Parameters

button

- button for which the repeat is set

---

The documentation for this class was generated from the following files:

• src/businesslogic/menu/PopUpMessageButtonHandler.h
• src/businesslogic/menu/PopUpMessageButtonHandler.cpp
